• Model: CA-1390
  • FOB Price : $3000-$5000/Set
  • Min Order Quantity: 1
  • Supply Ability: 300 Sets/Month
  • Payment Terms: L/C, T/T, West Union, Alibaba
  • Product Detail

    Product Tags

    Features:

    1.USB cable to transfer data and offline DSP control system are both available.

    <!--[if !supportLists]-->2.<!--[endif]-->Our three unique protection functions, i.e. anti-interference function, water-protective function and power cut-off function ensure longer working life, stability and effectiveness

    <!--[if !supportLists]-->3.<!--[endif]-->Exhausting, absorbing and assistant blowing systems solve the problem that troubles the laser equipment manufacturing industry for years, extending the life of the laser tube.

    <!--[if !supportLists]-->4.<!--[endif]-->It uses professional step motor and driver system. Mirror and lens are made of imported fibrous material, which can endure high temperature.

    Application:

    Applicable materials: acrylic,wood, MDF,bamboo, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials

    Applicable industries: advertisement, gift, shoes, toys, sign making,computers, garments, model cutting, building, packaging, paper industry

    Parameters:

    Type

    CA-1390

    Engraving Area

    1300*900mm

    Laser Power

    80/100/130/150W

    Laser Type

    CO2 Laser Tube

    Engraving speed

    0~60000mm/min

    Cutting speed

    0~36000mm/min

    Resetting positioning accuracy

    0.01mm

    Cutting depth

    Acryic 0-20mm(depend on different laser power and materials)

    Minimum Shaping Character

    1.5×1.5mm

    Power supply

    220V±10% 50HZ or 110V±10% 60HZ

    Gross power

    1200W

    Software supported

    ArtCut, CorelDraw, PhotoShop, AutoCAD

    Graphic format supported

    PLTDXFBMPJPGGIFPGNTIF

    Engraver for Curve surfaces (Yes/No)

    YES (we can add an Rotary attachment on the Laser Engrave/Cutting Machine, then the machine can engrave on Cylinder)

    Water Cooling: (Yes / No)

    Yes

    Maximum Height of Materials to

    Engrave (mm)

    400mm(Up and down by motor)

    Laser Tube (life hours)

                         5000-10000hours

    Assistant Equipment

    Water pump

    Exhaust Fan

    Flat bed worktable

    Optional Spare Parts

    100W/130W/150W Tube

    Rotary System

    Cooling water system

    Red Dot Pointer

    Up and down table

    Recommended Spare Parts / Consumables

    Laser Tube and Lens
